Shop SCHAEFER

Standard Duty Industrial Fan, Ceiling Mount, 36 in Blade Dia, 230/460V, 11,690 cfm, Non-Oscillating

  • Mfr # VKC36-3

  • Zoro # G5738844

product price:
$
612.99
/ea
Free Shipping & Returns

Key Features

Blade Diameter
36 in
Oscillation
Non-Oscillating
Number of Speeds
1
Voltage
230/460V AC
Phase
3
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
VKC36-3
Zoro #
G5738844
UPC #
-
Country of Origin
United States

Dimensions

Blade Diameter
36 in
Width
39 in
Max. Depth
20"
Outside Dia.
37-1/2"
Shaft Dia.
5/8 in
Height
39 in
Depth
20 in
Max. Mounting Height
Unrestricted

Details

Oscillation
Non-Oscillating
Number of Speeds
1
Voltage
230/460V AC
Phase
3
Motor HP
1/2 hp
Air Flow
11,690 cfm
Drive Type
Direct Drive
Blade Material
Steel
Item
Mounted Fan
Max. Ambient Temp.
104 Degrees F
Guard Material
Steel
Motor RPM
825
Assembled
Yes
Fan Style
Standard
Watts
364 W
CFM Low
11,693
Bearing Type
Ball
Wire Guard Finish
Powder Coated
Fan Mounting Location
Ceiling
Requires
Hard wire Installation
Motor Insulation
B
CFM High
11,693
Motor Enclosure
Totally Enclosed Air-Over
Hz
60 Hz
Motor Type
Permanent Split Capacitor
Number of Blades
3
Housing Material
Polyethylene
Fan Accessory Style
Standard
Thermal Protection
Auto
Mobile/Stationary
Stationary
Application
Spot Cooling and People Cooling
Environmental Applications
Industrial
Assembly Required
No
RPM
825 RPM
Fan Housing Material
Polyethylene
Wheeled Base
Stationary
Amps
2.3/1.2
Material
Polyethylene
Color
White
Motor hp
1/2 hp
Motor Design
Three-Phase
Standards
ANSI/AMCA Standard 230-99
Guard Color
White
Airflow
11,690 cfm
For Location
Barn, Warehouse
Mount Type
Cable

Description

Standard-Duty Industrial Fan, Blade Dia. 36 in, Stationary, Non-Oscillating, 1 Speeds, Voltage 230/460V AC, 3 Phase, CFM High 11,693, CFM Low 11,693, Motor HP 1/2 hp, Motor RPM 825, Operating Amps 2.3/1.2, Fan Mounting Location Ceiling, Fan Accessory Style Standard, Fan RPM 825, Max. Ambient Temp. 104 Degrees F, Hz 60 Hz, Watts 364, Motor Type Permanent Split Capacitor, Drive Type Direct Drive, Outside Dia. 37-1/2 In., Height 39 in, Width 39 in, Max. Depth 20 In.
