Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 4 P, Spring Type LC1G5004LSEA - main

IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 4 P, Spring Type

  • Mfr # LC1G5004LSEA

  • Zoro # G310354517

product price:  $4,254.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
200V-500V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G5004LSEA
Zoro #
G310354517
UPC #
3606481922793
Country of Origin
China

Dimensions

Overall Height
11.42 in
Overall Depth
4.8 in
Overall Width
7.28 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
200V-500V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Series
TeSys Giga
IP Rating
IP20
Mounting Style
Plate
Minimum Operating Temperature
-13 Degrees F
Mechanical Operating Durability
8,000,000
Frequency
50/60 Hz
Contactor Style
IEC
Embedded Surge Suppressor
No
Phase
Single
Maximum Voltage Rating
1000V AC
Maximum Operating Temperature
140 Degrees F
Includes Auxiliary Contacts
Yes
Full Load Current - Resistive
700 A
Full Load Current - Inductive
500 A

Description

The IEC Magnetic Contactor is a 4-pole, plate-mounted, single-phase device rated for operation within IEC-standard control systems. It contains an electromagnetic coil for switching contacts and has two auxiliary contacts (1NC/1NO). The unit features spring-type terminal connections, is rated for coil voltages between 200V and 500V (AC/DC), and is rated for a maximum voltage of up to 1000V AC. It belongs to the TeSys Giga series and does not include an embedded surge suppressor. Frequency support is 50/60 Hz, and the overall package accommodates a 50/60 Hz power environment.

Key features

  • Auxiliary contacts: 2 total (1NC/1NO)
  • Coil voltage: is rated for coil voltages between 200V and 500V (AC/DC)
  • Contactor style: IEC
  • Embedded surge suppressor: No
  • Frequency: 50/60 Hz
  • Full Load Amps: Inductive 630 A; Resistive 700 A
  • Full Load Current: Inductive 500 A; Resistive 700 A
  • IP rating: IP20
  • Maximum voltage rating: is rated for a maximum voltage of up to 1000V AC
  • Mechanical operating durability: 8,000,000 cycles
  • Operating temperature: -13°F to 140°F
  • Mounting style: Plate
  • Number of poles: 4
  • Dimensions (L/H/W): 4.8 in × 11.42 in × 7.28 in
  • Phase: Single
  • Series: TeSys Giga
  • Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • Terminal connection type: Spring Type

    • Restrictions

    WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
