  13. IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type
Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type LC1G8004EHEA - main

IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type

  • Mfr # LC1G8004EHEA

  • Zoro # G110190339

product price: $7,192.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G8004EHEA
Zoro #
G110190339
UPC #
3606481922717
Country of Origin
China

Dimensions

Overall Height
15.3 in
Overall Width
11.06 in
Overall Depth
10.47 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
IP Rating
IP20
Series
TeSys Giga
Contactor Style
IEC
Embedded Surge Suppressor
No
Maximum Operating Temperature
140 Degrees F
Minimum Operating Temperature
-13 Degrees F
Mounting Style
Plate
Phase
Single
Includes Auxiliary Contacts
Yes
Maximum Voltage Rating
1000V AC
Frequency
50/60 Hz
Mechanical Operating Durability
5,000,000
Full Load Current - Resistive
1,050 A
Full Load Current - Inductive
800 A

Description

The IEC Magnetic Contactor is a four-pole, coil-driven switching device that conforms to IEC standards for control devices. It features a 1NC/1NO auxiliary contact arrangement and is part of the TeSys Giga series (product classification only). The coil operates from 48–130 V (AC or DC) at 50/60 Hz, with spring-type terminals and plate mounting. It is rated for operation within the specified voltage ranges. It has an IP20 rating. It has an operational temperature range of -13°F to 140°F (as specified) and is specified for 5,000,000 mechanical operating cycles. Standards include CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1. It includes auxiliary contacts as specified.

Item: IEC Magnetic Contactor (TeSys Giga) (product classification only)

  • Poles/Phase: 4, Single
  • Coil Voltage: 48–130 V AC/DC
  • Auxiliary Contacts: 2 total (1NC/1NO)
  • Terminal Connection / Mounting: Spring Type, Plate
  • IP Rating: IP20
  • Maximum Voltage Rating: within the specified voltage ranges
  • Frequency: 50/60 Hz
  • Embedded Surge Suppressor: No
  • Full Load Amps: Inductive 900 A / Resistive 1,050 A
  • Full Load Current: Inductive 800 A / Resistive 1,050 A
  • Mechanical Durability: 5,000,000 cycles
  • Operating Temperature Range: -13°F to 140°F (as specified)
  • Dimensions: Depth 10.47 in, Height 15.3 in, Width 11.06 in
  • Series: TeSys Giga (product classification only)
  • Standards: CSA, EN/IEC, JIS, UL
  • Auxiliary Contacts Included: Yes
