Double Diaphragm Pump

Mfr # SP-B2/SP-8850-39
Zoro # G5092110

3,754.99

Free Shipping & Returns

Key Features

For Container Size

55 gal

Max. Flow Rate

31 gpm

Max. Viscosity

750 cps

Diesel Exhaust Fluid Compatible

Wetted Materials

PTFE, 316 Stainless Steel

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: SP-B2/SP-8850-39
Zoro #: G5092110
UPC #: -
Country of Origin: United States

Dimensions

For Container Size: 55 gal
Air Inlet Size: 1/4 in FNPT
Width: 6"
Manufacturers Warranty Length: 1 yr.
Height: 52"
Suction Tube Length: 41 in
Overall Length: 53 in
Air Outlet Size: 3/8 in
Air Inlet Connection Size: 1/4 in
Wire Rope Length: 53 in
Length: 53 in

Details

Item: Air Drum Pump
Max. Flow Rate: 31 gpm
Max. Viscosity: 750 cps
Diesel Exhaust Fluid Compatible: No
Wetted Materials: PTFE, 316 Stainless Steel
Includes Suction Tube: Yes
For Use With: 454U40
Discharge Tube Outlet ID: 1 1/2 in
Discharge Tube Outlet OD: 1 1/2 in
Agency Compliance: 3A, FDA Compliant
Includes: Motor, Pump
Housing Material - Pumps: 316 Stainless Steel
Self-Priming: Yes
Includes Spout: No
Variable Speed: Yes
Motor RPM: 0 - 10,000
Max. Head Pressure: 8 psi
Max. Fluid Temp.: 175 Degrees F
Duty Cycle: Intermittent
Food Grade: Yes
Discharge Connection Type: Tri-Clamp
Motor HP: 3/4 hp
Max. Air Pressure: 100 psi
Includes Nozzle: No
Metered: No
For Container Type: Drum
Seal Material: Sealless
Max. Oil Flow: 5 gpm
Runs Dry: Yes
Noise Level: 87 dB
Power Source: Air
Includes Discharge Hose: No
Suction Tube Material: Stainless Steel
Includes Bung Adapter: No
Max. Head - Pumps: 18 ft
Explosion Proof: Yes
Maximum Flow Rate: 31 gpm
Wetted Material: 316 SS/Buna-N/PTFE
Maximum Oil Flow: 5 gpm
Meter Type Included: No Meter Included
Maximum Air Pressure: 100 psi
Motor Horsepower: 3/4 hp
Maximum Head: 18 ft
Maximum Viscosity: 750 cps
Maximum Head Pressure: 8 psi
Air Inlet Connection Type: FNPT
Housing Material: 316 Stainless Steel
Standards: 3A, FDA
Maximum Fluid Temperature: 175 Degrees F
Power Source - TS Only: Air
Power Source - old: Air

Description

Air Drum Pump, Max. Air Pressure 100 psi, Spout Connection Size Not Applicable, Suction Tube Material Stainless Steel, Self-Priming Yes, Length 53 in, Explosion Proof Yes, Discharge Connection Type Tri-Clamp, Spout Length Not Applicable, Food Grade Yes, Air Outlet Size 3/8 in, Motor HP 3/4 hp, Variable Speed Yes, Includes Discharge Hose No, Noise Level 87 dB, Max. Viscosity 750 cps, Duty Cycle Intermittent, Includes Suction Tube Yes, Includes Bung Adapter No, Includes Nozzle No
