Shop TELEMECANIQUE SENSORS

Pressure Switch, Standard, 1C/O, Steel

  • Mfr # XMLB010A2S11
  • Zoro # G4062883
product price:
$
313.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
1C/O
Housing Material
Steel
Standards
UL 508; CSA C22.2 No 14; EN/IEC 60947-5-1; CE; LROS (Lloyds register of shipping); CCC; BV; EAC
IP Rating
IP66
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XMLB010A2S11
Zoro #
G4062883
UPC #
-
Country of Origin
United States

Dimensions

Manufacturer Warranty Length
18 mo
Overall Height
113 mm
Overall Width
35 mm
Overall Depth
75 mm
Fits Chest Size
Designed for Regulation of Pressure Between Two Thresholds for Air, Fresh Water and Hydraulic Oils at Temperatures up to 158 Degrees F

Details

Item
Pressure Switch
Action
Standard
Contact Form
1C/O
Housing Material
Steel
Standards
UL 508; CSA C22.2 No 14; EN/IEC 60947-5-1; CE; LROS (Lloyds register of shipping); CCC; BV; EAC
IP Rating
IP66
Material
Zinc alloy
Burst Pressure
45 bar
Temp. Range
-25 Degrees to 70 Degrees C
Max. Pressure
12.5 bar
Electrical Connection
Screw-Clamp Terminal
Special Features
Local Display; Mercury Free; Green Premium product
Product Type
Water and Air Pressure Switch
Media Temperature - Maximum
158 Degrees F
Overload Protection - Maximum
10 A
Differential Pressure - Maximum
109 psi
Pressure - Minimum
10.15 psi
Pressure - Maximum
145 psi
Operating Temperature - Maximum
158 Degrees F
Proof Pressure
326 psi
DC Contact Rating
0.1 A @ 250 V
Number of Pressure Connection Ports
1
AC Contact Rating
1.5 A @ 240 V, 3 A @ 120 V
Pressure Connection Type
1/4" BSPP
Compatible Media
Compressed Air, Liquid
Actuator Style
Diaphragm
Unloader
No Unloader Included
Differential Pressure - Minimum
8.27 psi
Features
Designed for Regulation of Pressure Between Two Thresholds for Air, Fresh Water and Hydraulic Oils at Temperatures up to 158 Degrees F
Switch Function Configuration
On/Off
Deadband Adjustability
Adjustable
Media Temperature - Minimum
32 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Series
XM
Pressure Switch Action Type
Standard

Description

Pressure switch XMLB 10 bar - adjustable
