DigitalClampMeter, TRMS, 1000A, 1000VAC

Mfr # CM1000-NIST
Zoro # G322440734

307.99

Free Shipping & Returns

Key Features

Auto Ranging

Yes

Frequency Measurement Accuracy

+/-1.2%

Maximum Frequency Measurement

100 kHz

Memory

Min/Max

True RMS Bandwidth

400 Hz

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: CM1000-NIST
Zoro #: G322440734
UPC #: 614395003364
Country of Origin: China

Dimensions

True RMS Bandwidth: 400 Hz
Overall Width: 3.2 in
Battery Size: AAA
Manufacturers Warranty Length: 1 yr
Overall Height: 9.9 in

Details

Auto Ranging: Yes
Frequency Measurement Accuracy: +/-1.2%
Maximum Frequency Measurement: 100 kHz
Memory: Min/Max
Jaw Opening: 1.4 in
Standards: cETLus
Basic AC Voltage Accuracy: +/-1.5%
AC Response Calculation: TRMS
Minimum AC Current Measurement: 0 A
Diode Test: Yes
Data Logging: No
Thermometer Type: Type K Thermocouple
Calibration Certificate Included: NIST Traceable
Maximum DC Voltage Measurement: 1,000 V
Basic AC Current Accuracy: +/-2.8%
Parameters Measured: AC Current, AC Voltage, Capacitance, Continuity, DC Voltage, Diode, Duty Cycle, Frequency, Low Pass Filter, Resistance, Temperature, Variable Frequency Drive
Software Included: No
Peak Hold: No
Capacitance Measurement Accuracy: +/-5%
Intrinsically Safe: No
Display Type: Backlit LCD
Batteries Included: Yes
Current Leakage Testing: No
Inrush Current Measurable: Yes
Minimum Frequency Measurement: 10 Hz
Minimum Resistance Measurement: 600 ohm
Maximum AC Current Measurement: 1,000 A
Minimum Storage Temperature: -4 Degrees F
Temperature Types Measured: Temperature Degrees C, Temperature Degrees F
Maximum Capacitance Measurement: 100 mF
Jaw Style: Clamp
Audible Continuity: Yes
CAT Safety Rating: CAT IV 600V
Minimum AC Voltage Measurement: 6 V
Time of Day Clock: No
Thermal Imaging: No
Resistance Measurement Accuracy: +/-3.5%
Bar Graph Included: No
Includes: (3) Batteries, Carrying Case, Test Leads, Type K Thermocouple Bead Probe
Maximum Resistance Measurement: 60 megaohm
Minimum Capacitance Measurement: 60 nF
Multiple On-Screen Displays: No
Data Hold: Yes
Basic DC Voltage Accuracy: +/-1.5%
Maximum AC Voltage Measurement: 1,000 V
Non-Contact Voltage Detector: Yes
Item: Digital Clamp Meter
Battery Access: Yes
IP Rating: Not Rated
Instrument Counts: 6,000
Maximum Storage Temperature: 140 Degrees F
Minimum DC Voltage Measurement: 0 V
Battery Voltage: 1.5 V
Voltage Units: mV, V
Removable Screen: No
Special Features: Lo Z (Impedance) Mode, Low Pass Filter
Includes Auto Sensing: No Auto Sensing Included
Auto Power Off: Yes
Minimum Operating Temperature: -4 Degrees F
Current Units: A

Description

Digital Clamp Meter, Audible Continuity Yes, AC Response Calculation TRMS, Maximum AC Current Measurement 1,000 A, Maximum AC Voltage Measurement 1,000 V, Maximum DC Current Measurement Not Applicable, Maximum DC Voltage Measurement 1,000 V, Current Leakage Testing No, IP Rating Not Rated, Parameters Measured AC Current, AC Voltage, Capacitance, Continuity, DC Voltage, Diode, Duty Cycle, Frequency, Low Pass Filter, Resistance, Temperature, Variable Frequency Drive, Intrinsically Safe No
