Shop U.S. MOTORS

Belt Drive Motor, Brand Amana

  • Mfr # U32L9C

  • Zoro # G2103338

product price:
$
796.99
/ea
Free Shipping & Returns

Key Features

Body Dia.
6 3/4 in
Voltage Compatibility
200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 220-230/460V AC, 220/460V AC, 230/460/796V AC, 230/460V AC, 440-460V AC, 460/796V AC, 460V AC
HP
1 1/2, 3/8
Motor Application
General Application
Full Load Amps
2.4 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
U32L9C
Zoro #
G2103338
UPC #
786382043742
Country of Origin
Mexico

Dimensions

Body Dia.
6 3/4 in
Shaft Length
2 1/4 in
Shaft Dia.
7/8 in
Length Less Shaft
10 3/4 in
Overall Length
13 in
Frame Size
145T
Shaft Diameter
7/8 in
Body Diameter
6.8 in

Details

Voltage Compatibility
200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 220-230/460V AC, 220/460V AC, 230/460/796V AC, 230/460V AC, 440-460V AC, 460/796V AC, 460V AC
HP
1 1/2, 3/8
Motor Application
General Application
Full Load Amps
2.4 A
Motor Shaft Rotation
CW/CCW
Motor Service Factor
1.25
Standards
UL (E51488), CSA (191252), CE
Max. Ambient Temp.
104 Degrees F
Ins. Class
F
Voltage
460V AC
No. of Speeds
2
Nameplate RPM
1,740/860
Motor Mounting Type
Rigid Base
Phase
Three
Hz
60 Hz
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Shaft Design
Keyed
RPM Range
Over 3,600
Item
Direct Drive Blower Motor
Duty
Continuous
Capacitor Required
Capacitor Not Required
Motor Design
3-Phase
Motor Bearings
Ball
Motor Thermal Protection
None
Motor Sub Application
Belt Drive Fan/Blower
Frame
145T
OEM Replacement Brand
Amana
Number of Shafts
1
Duty Cycle
Continuous
Ambient Temperature - Maximum
40 Degrees C
Shaft Design
Keyed
Motor Enclosure Type
Totally Enclosed Fan Cooled
Nameplate Service Factor @ 60 Hz
1.25
Drive Type
Belt Drive
Number of Speeds
2
Insulation Class
F
Full Load Current @ 60 Hz
2.4 A
Frequency
60 Hz

Description

Belt Drive Motor, Three Phase, Motor Design Three-Phase, 1 1/2 hp, 3/8 hp HP, Nameplate RPM 1,740/860, No. of Speeds 2, Voltage 460V AC, 2.4 A Full Load Amps, 145T Frame, 60 Hz Hz, Motor Service Factor 1.25, Motor Thermal Protection None, Ins. Class F, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Mounting Type Rigid Base, Shaft Length 2 1/4 in, Shaft Dia. 7/8 in
