Shop U.S. MOTORS

Split-Phase General Purpose Motor, 1/2 hp HP, 115V AC Voltage, 56 Frame, 1,725 RPM Nameplate RPM

  • Mfr # 3306

  • Zoro # G4403806

product price:  $410.99
/ea
Free Shipping & Returns

Key Features

Motor Enclosure Design
Open Drip Proof
Motor Mounting Type
Cradle Base
HP
1/2 hp
RPM Range
1,701-1,800
Voltage
115V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
3306
Zoro #
G4403806
UPC #
786382003197
Country of Origin
Mexico

Dimensions

Overall Length
10 3/4 in
Length Less Shaft
8 7/8 in
Shaft Dia.
5/8 in
Shaft Length
1 7/8 in
Body Diameter
6.44 in
Shaft Diameter
5/8 in
Frame Size
56
Wire Rope Length
10 3/4 in

Details

Item
General Purpose Motor
Motor Enclosure Design
Open Drip Proof
Motor Mounting Type
Cradle Base
HP
1/2 hp
RPM Range
1,701-1,800
Voltage
115V AC
Frame
56
Motor Thermal Protection
None
Motor Service Factor
1
No. of Speeds
2
Voltage Compatibility
115V AC
Motor Application
General Purpose
Nameplate RPM
1,725 RPM
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Design
Split-Phase
Standards
CSA Certified, UL Recognized
Full Load Amps
9.2/5.2 A
Hz
60 Hz
Max. Ambient Temp.
40 Degrees C
Ins. Class
B
Motor Bearings
Ball
Phase
Single
Weight
28 lb
Duty Cycle
Continuous
Usable @ 200V
Not Usable at 200V
Conduit Box Location
Interior
Usable @ 208V
Not Usable at 208V
Insulation Class
B
Ambient Temperature - Maximum
40 Degrees C
Full Load Current @ 60 Hz
9.2/5.2 A
Product Type
General Purpose Motor
Bearing Type
Ball
Motor Enclosure Type
Open Drip Proof
Number of Speeds
2
Application
General Purpose
Nameplate Service Factor @ 60 Hz
1
Shaft Design
Keyed
Frequency
60 Hz

Description

General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 2, Voltage 115V AC, Full Load Amps 9.2/5.2 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
