  11. 3-Phase Belt Drive Motor, 5 HP, 56HZ Frame, 208-230/460V AC Voltage, 3,450 Nameplate RPM
Century

3-Phase Belt Drive Motor, 5 HP, 56HZ Frame, 208-230/460V AC Voltage, 3,450 Nameplate RPM

Century 3-Phase Belt Drive Motor, 5 HP, 56HZ Frame, 208-230/460V AC Voltage, 3,450 Nameplate RPM H1039L
Tap to zoom
Hover or click to zoom
$659.99
  • Item: Belt Drive Motor
  • Motor Design: 3-Phase
  • Motor Enclosure Design: Open Dripproof
See full product details
This item ships free.
Total: $659.99

Century #H1039L Specifications

  • Item: Belt Drive Motor
  • Motor Design: 3-Phase
  • Motor Enclosure Design: Open Dripproof
  • HP: 5
  • No. of Speeds: 1
  • RPM Range: 3,001-3,600
  • Nameplate RPM: 3,450
  • Voltage: 208-230/460V AC
  • Frame: 56HZ
  • Motor Mounting Type: Cradle Base
  • Shaft Dia.: 7/8 in
  • Motor Thermal Protection: Auto
  • Motor Service Factor: 1.15
  • Voltage Compatibility: 200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC
  • Phase: Three
  • Motor Application: HVAC/R
  • Motor Sub Application: Belt Drive Fan/Blower
  • Body Dia.: 6 5/8 in
  • Resilient Ring Dia.: 2 1/2 in
  • Shaft Length: 2 5/16 in
  • Full Load Amps: 13.4-13.2/6.6
  • Duty: Continuous
  • Mounting Stud Pattern: 4 1/8 in x 4 1/8 in
  • Footnotes: 15
  • Motor Mounting Position: All Angle
  • Nominal Efficiency: 85.2 %
  • Ins. Class: B
  • Standards: CSA, UL Recognized
  • Ring to Ring Center: 11 15/16 in
  • Hz: 60
  • Max. Ambient Temp.: 40 Degrees C
  • Overall Length: 14 9/16 in
  • Frame Material: Steel
  • Motor Shaft Rotation: CW/CCW
  • Length Less Shaft: 12 1/4 in
  • Motor Bearings: Ball
  • Motor Frame Material: Steel
  • Usable @ 200V: No
  • Weight: 50 lb
  • Usable @ 208V: Yes
  • Duty Cycle: Continuous
  • Country of Origin (subject to change): Mexico

Description

Belt Drive Motor, Three Phase, Motor Design 3-Phase, 5 HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 208-230/460V AC, 13.4-13.2/6.6 Full Load Amps, 56HZ Frame, Usable @ 208V Yes, Usable @ 200V No, 60 Hz, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle, Motor Frame Material Steel
