Diaphragm Pump, Polypropylene, Santoprene, 24VDC, 2.0 GPM 140 Degrees F

  • Mfr # 7812-201-SB-HS-24

  • Zoro # G1593790

product price:  $124.99
/ea
Free Shipping & Returns

Key Features

Housing Material - Pumps
Polypropylene
Valve Material
Viton®
Air Intake Connection Size
5/8 in QC
Diaphragm Material
Santoprene
Media Temperature (Maximum)
140 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
7812-201-SB-HS-24
Zoro #
G1593790
UPC #
830344009335
Country of Origin
United States

Dimensions

Air Intake Connection Size
5/8 in QC
Overall Length
8.5 in
Overall Width
4 in
Overall Height
3.5 in
Media Intake Connection Size
5/8 in
Media Discharge Connection Size
5/8 in
Discharge Connection Size
5/8 in
Intake Connection Size
5/8 in
Inlet Diameter
5/8 in
Discharge Diameter
5/8 in
Shaft Outer Diameter
8 mm

Details

Item
Diaphragm Pump
Housing Material - Pumps
Polypropylene
Valve Material
Viton®
Diaphragm Material
Santoprene
Media Temperature (Maximum)
140 Degrees F
Operating Pressure (Maximum)
60 psi
Pressure On
20 psi
Agency Compliance
CE/NSF
Motor Type
Totally enclosed Nonventilated
Prime in Feet
8
Diaphragm Design
Three Chamber
Type
Diaphragm
Pressure Off
60 psi
Inlet/Outlet
5/8 QC
Fuse Amps
3 A
Features
Heat Sink On Motor to Keep It Cool
Pressure Switch
Yes
Standards
NSF Certified
Pump Operation Type
Electric
Motor Enclosure
Totally Enclosed Non-Ventilated
Flow Rate (Maximum)
2 gpm
Flow Rate @ 20 psi
1.6 gpm
Current
3 A
Nameplate Voltage
24V DC
Flow Rate @ 40 psi
1.5 gpm
Diaphragm Chamber Design
3
Flow Rate @ 60 psi
1.1 gpm
Flow Rate @ 0 psi
1.7 gpm
Priming
Self-Priming
Series
7800
Media Intake Connection Type
Quick Connect
Media Discharge Connection Type
Quick Connect
Discharge Connection Type
Quick Connect
Check Valve Material
FKM
Housing Material
Polypropylene
Intake Connection Type
Quick Connect
Gasket Material
FKM
Pump Technology
Diaphragm
Includes Gearbox
No Gearbox Included
Chemical Compatibility
Fertilizer, Herbicide
Discharge Pressure - Maximum
60 psi
Fluid Head Material
Polypropylene
Self-Priming Lift - Maximum
12 ft
Electrical Connection Type
Power Cord with Plug
Full Load Current
22.5
Feet of Head (Maximum)
138.4 ft
Pump Drive Configuration
Electric Motor Unit
Includes Heat Sink
Heat Sink Included
Pump Control Type
Demand
Number of Diaphragms
1
Pressure Switch On Pressure
50 psi
Includes Regulator
No Regulator Included
Pumping Application
Boom Spraying, Chemical Transfer, Deicing, Disinfectant/Sanitizer Spraying, Fertilizer Application, Herbicide Spraying, Irrigation, Lawn Care, Orchard Spraying, Pest Control, Pesticide Spraying, Soft Wash, Turf Spraying, Vineyard Spraying, Water Transfer
Phase
Single
Inlet Standard
Quick Connect
Motor Speed - Maximum
2,200 RPM
Power Source
Electric
Discharge Standard
Quick Connect
Pressure Switch Off Pressure
60 psi
Media Temperature - Maximum
140 Degrees F
Power Source - TS Only
Electric

Description

Diaphragm Pump, Operating Pressure (Maximum) 60 psi, Diaphragm Chamber Design 3, Diaphragm Material Santoprene, Check Valve Material FKM, Discharge Connection Size 5/8 in, Discharge Connection Type Quick Connect, Flow Rate (Maximum) 2 gpm, Housing Material Polypropylene, Intake Connection Size 5/8 in, Intake Connection Type Quick Connect, Nameplate Voltage 24V DC, Priming Self-Priming, Pump Operation Type Electric, Pressure Switch Yes, Standards NSF Certified, Flow Rate @ 60 psi 1.1 gpm
