  9. Fuel Transfer Pump, 115V AC, 13 gpm Max. Flow Rate , 1/4 HP, Polypropylene, 1 in NPT Inlet
Fill-Rite Fuel Transfer Pump, 115V AC, 13 gpm Max. Flow Rate , 1/4 HP, Polypropylene, 1 in NPT Inlet SS460BX674 - main

Fuel Transfer Pump, 115V AC, 13 gpm Max. Flow Rate , 1/4 HP, Polypropylene, 1 in NPT Inlet

  • Mfr # SS460BX674

  • Zoro # G4315985

product price: $769.99
/ea
Free Shipping & Returns

Key Features

Voltage
115V AC
Application
Agricultural; Industrial Chemicals and Lubricants
HP
1/4
Housing Material
Polypropylene
GPM
13 gpm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
SS460BX674
Zoro #
G4315985
UPC #
089404213292
Country of Origin
United States

Dimensions

Inlet Size
1 in NPT
Outlet Size
1 in NPT
Overall Width
14 in
Overall Height
6 1/4 in
Overall Length
8 3/4 in
Pump Mount Size
2 in
Manufacturers Warranty Length
5 yr
Cord Length
6 5/8 ft
For Container Size
330 gal

Details

Voltage
115V AC
Application
Agricultural; Industrial Chemicals and Lubricants
HP
1/4
Housing Material
Polypropylene
GPM
13 gpm
Seal Material
EPDM
RPM
2600
Pump Design
Santoprene Diaphragm
Self-Priming
No
Seal Type
O-ring
Max. Viscosity
30 SUS
Item
Fuel Transfer Pump
Duty Cycle
30 Minutes On/30 Minutes Off
Bypass Valve
No
Pressure Range
15 psi
Features
Automatically Goes Neutral, Glass-Reinforced Polypropylene Pump Housing, Spring Driven Configuration
Bearing Type
Ball
Metered
No
Includes
Plastic Straight Flange and Chemical Fittings
For Use With
Fertilizers, Mild Acid, Pesticides, Water
Transfer Pump Application
Agriculture, Construction, Farming
Compatible Fluids
Fertilizers, Mild Acid, Pesticides, Water
Amps AC
5.5
Motor Type
Permanent Magnet
Housing Material - Pumps
Polypropylene
Motor RPM
2,600 RPM
Thermal Protection
Yes
Nozzle Fluid Compatibility
Gasoline
Power Source
Electric
Max. Flow Rate
13 gpm
Full Load Amps
5.5 A
Rated Voltage
115V AC
Compatible Chemicals
Fertilizers, Herbicides, Mild Acid, Pesticides, Water
Motor HP
1/4 hp
Max. Outlet Pressure
15 psi
For Media Type
Fertilizers, Herbicides, Mild Acid, Pesticides, Water

Description

Electric Drum Pump, Max. Outlet Pressure 15 psi, For Use With Fertilizers, Mild Acid, Pesticides, Water, Rated Voltage 115 V AC, Plug Type Not Applicable, Pump Connection ID 1 in, Suction Tube OD Not Applicable, Hose Length Not Applicable, Suction Tube Length Not Applicable, Cord Length 6 5/8 ft, Includes Bung Adapter Yes, Nozzle Operation Not Applicable, Thermal Protection Yes, Power Source Corded Electric, Variable Speed No, Includes Discharge Hose No, Self-Priming No
