Shop FILL-RITE

Fuel Transfer Pump, 115V AC, 13 gpm Max. Flow Rate , 1/4 HP, Polypropylene, 1 in NPT Inlet

  • Mfr # SS460BX674

  • Zoro # G4315985

product price:
$
778.99
/ea
Free Shipping & Returns

Key Features

Voltage
115V AC
Application
Agricultural; Industrial Chemicals and Lubricants
HP
1/4
Housing Material
Polypropylene
GPM
13 gpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SS460BX674
Zoro #
G4315985
UPC #
089404213292
Country of Origin
United States

Dimensions

Inlet Size
1 in NPT
Outlet Size
1 in NPT
Overall Width
14 in
Overall Height
6 1/4 in
Overall Length
8 3/4 in
Pump Mount Size
2 in
Manufacturers Warranty Length
5 yr
Cord Length
6 5/8 ft
For Container Size
55 gal, 330 gal, 350 gal
Adapter Connection Diameter
2 in
Wire Rope Length
8 3/4 in
Length
8 3/4 in

Details

Voltage
115V AC
Application
Agricultural; Industrial Chemicals and Lubricants
HP
1/4
Housing Material
Polypropylene
GPM
13 gpm
Seal Material
EPDM
RPM
2600
Pump Design
Santoprene Diaphragm
Self-Priming
No
Seal Type
O-ring
Max. Viscosity
30 SUS
Item
Electric Drum Pump
Duty Cycle
30 Minutes On/30 Minutes Off
Bypass Valve
No
Pressure Range
15 psi
Features
Automatically Goes Neutral, Glass-Reinforced Polypropylene Pump Housing, Spring Driven Configuration
Bearing Type
Ball
Metered
No
Includes
Plastic Straight Flange and Chemical Fittings
For Use With
Fertilizers, Mild Acid, Pesticides, Water
Transfer Pump Application
Agriculture, Construction, Farming
Compatible Fluids
Fertilizers, Mild Acid, Pesticides, Water
Amps AC
5.5 A
Motor Type
Permanent Magnet
Housing Material - Pumps
Polypropylene
Motor RPM
2,600 RPM
Thermal Protection
Yes
Power Source
Corded Electric
Max. Flow Rate
13 gpm
Full Load Amps
5.5 A
Rated Voltage
115 V AC
Compatible Chemicals
Fertilizers, Herbicides, Mild Acid, Pesticides, Water
Motor HP
1/4 hp
Max. Outlet Pressure
15 psi
For Media Type
Fertilizers, Herbicides, Mild Acid, Pesticides, Water
Static Protection
No Grounding Line Included
Includes Follower Plate
No Follower Plate Included
Motor Horsepower
1/4 hp
Minimum Fluid Temperature
-40 Degrees F
For Container Type
Drum
Includes Nozzle
No
Chemical Compatibility
Fertilizers, Herbicides, Pesticides, Water
Maximum Outlet Pressure
15 psi
Container Type Included
Drum
Includes Suction Tube
No
Adapter Connection Standard
MNPT
Maximum Head
37 ft
Variable Speed
No
Pump Technology
Diaphragm
Includes Bung Adapter
Yes
Maximum Fluid Temperature
150 Degrees F
Wetted Material
Buna-N/Santoprene/Stainless Steel
Motor Speed
2,600 RPM
Pump Connection OD
1 3/8 in
Maximum Flow Rate
13 gpm
Motor Enclosure Design
Totally Enclosed Non-Ventilated
Pump Connection ID
1 in
Meter Type Included
No Meter Included
Container Cover Type Included
No Cover Included
Includes Discharge Hose
No
Full Load Current
5.5 A
Discharge Connection Type
FNPT
Maximum Viscosity
30 SUS
Includes Spout
No
Power Source - TS Only
Corded Electric
Power Source - old
Corded Electric

Description

Electric Drum Pump, Max. Outlet Pressure 15 psi, For Use With Fertilizers, Mild Acid, Pesticides, Water, Rated Voltage 115 V AC, Plug Type Not Applicable, Pump Connection ID 1 in, Suction Tube OD Not Applicable, Hose Length Not Applicable, Suction Tube Length Not Applicable, Cord Length 6 5/8 ft, Includes Bung Adapter Yes, Nozzle Operation Not Applicable, Thermal Protection Yes, Power Source Corded Electric, Variable Speed No, Includes Discharge Hose No, Self-Priming No
