Shop FILL-RITE

Fuel Transfer Pump, 24V DC, 15 gpm Max. Flow Rate , 1/4 HP, Cast Iron, 1 in Inlet

  • Mfr # FR2410H

  • Zoro # G9791442

product price:
$
570.99
/ea
Free Shipping & Returns

Key Features

Voltage
24V DC
Application
Designed for Gasoline, Diesel, Biodiesel Up to B20, E15, Kerosene and Mineral Spirit
HP
1/4
Housing Material
Cast Iron
GPM
15 gpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
FR2410H
Zoro #
G9791442
UPC #
089404223123
Country of Origin
United States

Dimensions

Inlet Size
1 in
Pump Mount Size
2 in
Suction Tube Length
34 1/2 in
Overall Length
12 1/4 in
Overall Width
9 in
Outlet Size
3/4 in
Hose Length
12 ft
Power Cord Length
18 ft
Hose Dia.
3/4 in
Overall Height
9 in
Manufacturers Warranty Length
2 yr
Cord Length
18 ft
Hose Outside Dia.
3/4 in
For Container Size
35 gal, 55 gal, 275 gal, 500 gal
Spout Length
6 in
Adapter Connection Diameter
2 in
Hose Inside Diameter
3/4 in
Hose Outside Diameter
1 1/8 in
Spout Discharge Size
3/4 in
Wire Rope Length
12 1/4 in
Length
12 1/4 in

Details

Voltage
24V DC
Application
Designed for Gasoline, Diesel, Biodiesel Up to B20, E15, Kerosene and Mineral Spirit
HP
1/4
Housing Material
Cast Iron
GPM
15 gpm
Seal Material
Buna-N
RPM
2600
Pump Design
Rotary Vane
Self-Priming
Yes
Seal Type
O-ring
Max. Viscosity
39.5 SUS
Item
Electric Drum Pump
Transfer Pump Application
Agriculture, Barrel Mounting, Construction, Stationary Installations, Tank
Bearing Type
Adjustable
Standards
cULus
Duty Cycle
30 Minutes On/30 Minutes Off
Compatible Fluids
Biodiesel, Diesel, Gasoline
Pressure Range
16 psi
Nozzle Type
Manual
Bypass Valve
Yes
Metered
No
Motor Type
Permanent Magnet
Agency Compliance
cULus
Wetted Materials
Buna-N, Ceramic, Cork, Stainless Steel, Steel, Thermoset, Viton
Includes
Cable
Nozzle Material
Aluminum
Max. Head - Pumps
37 ft
Housing Material - Pumps
Cast Iron
Motor RPM
2,600 RPM
Runs Dry
Yes
Mount Type
Bung
Includes Discharge Hose
Yes
Max. Head Pressure
16 psi
Nozzle Fluid Compatibility
Diesel
Rated Voltage
24 V DC
Full Load Amps
15.0 A
Nozzle Operation
Manual
For Media Type
Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits
Includes Nozzle
Yes
Max. Outlet Pressure
16 psi
Power Source
Corded Electric
Max. Flow Rate
15 gpm
Includes Suction Tube
Yes
Discharge Connection Type
FNPT
Compatible Chemicals
Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits
Motor HP
1/4 hp
Thermal Protection
Yes
Pump Connection Type
NPT
Minimum Fluid Temperature
-40 Degrees F
Pump Technology
Vane
Suction Tube OD
1 5/16 in
Adapter Connection Standard
MNPT
Motor Speed
2,600 RPM
Container Cover Type Included
No Cover Included
Maximum Outlet Pressure
16 psi
Includes Spout
Yes
Hose Cover Material
Neoprene
Maximum Head
37 ft
Includes Follower Plate
No Follower Plate Included
Maximum Viscosity
39.5 SUS
Motor Enclosure Design
Totally Enclosed Non-Ventilated
Pump Connection OD
1 1/8 in
Wetted Material
Buna-N/Ceramic/Cork/Stainless Steel/Steel/Thermoset/Viton
Variable Speed
No
Hose Tube Material
Nitrile
Static Protection
Grounding Line Included
Container Type Included
Drum
Maximum Fluid Temperature
150 Degrees F
Meter Type Included
No Meter Included
Pump Connection ID
3/4 in
Full Load Current
15 A
Includes Bung Adapter
Yes
For Container Type
Tank
Suction Tube Material
Steel
Motor Horsepower
1/4 hp
Suction Tube ID
1 3/16 in
Maximum Flow Rate
15 gpm
Spout Material
Aluminum
Chemical Compatibility
Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits
Hazardous Location Class
Class I/Division 1
Maximum Head Pressure
16 psi
Power Source - TS Only
Corded Electric
Power Source - old
Corded Electric

Description

Electric Drum Pump, Max. Head Pressure 16 psi, Max. Outlet Pressure 16 psi, Rated Voltage 24 V DC, Plug Type Not Applicable, Pump Connection ID 3/4 in, Suction Tube OD 1 5/16 in, Hose Length 12 ft, Suction Tube Length 34 1/2 in, Cord Length 18 ft, Includes Bung Adapter Yes, Runs Dry Yes, Nozzle Operation Manual, Thermal Protection Yes, Power Source Corded Electric, Variable Speed No, Includes Discharge Hose Yes, Self-Priming Yes
