Flint & Walling

Deep Well Submersible Pump Motor, 1/2 HP

original price: $792.99
29% off
new price: $557.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Phase Single
  • Dia. 3 3/4 in
  • HP 1/2
  • Voltage 115V AC
  • Number of Wires 2
See all product information

Product Information

Dimensions

Dia. 3 3/4 in
Height 10 1/8 in
Lead Length 48 in
Body Dia. 4 in
Overall Length 11 5/8 in
Length Less Shaft 10 1/8 in

Details

Item Deep Well Submersible Pump Motor
Phase Single
HP 1/2
Voltage 115V AC
Number of Wires 2
RPM Range 3,001-3,600
Motor Service Factor 1.6
Motor Bearings Sleeve
Nameplate RPM 3,450
Motor Sub Application Deep Well Submersible Pump
Stator Type Hermetically Sealed
Motor Application Pump
Max. Ambient Temp. 86 Degrees F
Shaft Material Stainless Steel
Standards CSA (C22.2 No. 100-14), NSF/ANSI 61
Starter Required No
Max. SF Amps 12.0
Shell Material Stainless Steel
Thrust Rating 700 lb
Motor Shaft Rotation CWSE
Hz 60 Hz
Full Load Amps 10.0
Motor Enclosure Design Totally Enclosed Nonventilated
Overload Relay Required No
Diaphragm Type Pressure Equalizing
Motor Design Split-Phase
Motor Thermal Protection Auto
Motor Shaft Design Spline
Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
No. of Speeds 1
Usable @ 200V No
Usable @ 208V No
Motor Mounting Position Vertical Shaft Up

Description

Deep Well Submersible Pump Motor, Body Dia. 4 in, Diaphragm Type Pressure Equalizing, Hz 60 Hz, Full Load Amps 10.0, Height 10 1/8 in, HP 1/2, Lead Length 48 in, Length Less Shaft 10 1/8 in, Max. Ambient Temp. 86 Degrees F, Max. SF Amps 12.0, Motor Application Pump, Motor Bearings Sleeve, Motor Design Split-Phase, Motor Enclosure Design Totally Enclosed Nonventilated
