Flint & Walling Deep Well Submersible Pump Motor, 3/4 HP 137416 - main

Deep Well Submersible Pump Motor, 3/4 HP

  • Mfr # 137416

  • Zoro # G2553542

product price:  $955.80
/ea
Free Shipping & Returns

Key Features

Phase
Single
Dia.
3 3/4 in
HP
3/4
Voltage
230V AC
Number of Wires
2
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
137416
Zoro #
G2553542
UPC #
054757035914
Country of Origin
United States

Dimensions

Dia.
3 3/4 in
Height
11 15/16 in
Lead Length
48 in
Length Less Shaft
11 1/4 in
Body Dia.
4 in
Overall Length
12 3/4 in
Body Diameter
4 in
Shaft Diameter
5/8 in

Details

Item
Deep Well Submersible Pump Motor
Phase
Single
HP
3/4
Voltage
230V AC
Number of Wires
2
RPM Range
3,001-3,600
Motor Service Factor
1.5
Motor Bearings
Sleeve
Nameplate RPM
3,450
Thrust Rating
700 lb
Motor Shaft Rotation
CWSE
Stator Type
Hermetically Sealed
Hz
60 Hz
Motor Sub Application
Deep Well Submersible Pump
Motor Design
Split-Phase
Motor Thermal Protection
Auto
Motor Application
Pump
Shaft Material
Stainless Steel
Motor Enclosure Design
Totally Enclosed Nonventilated
Overload Relay Required
No
Shell Material
Stainless Steel
Max. Ambient Temp.
86 Degrees F
Starter Required
No
Full Load Amps
6.8
Standards
CSA (C22.2 No. 100-14), NSF/ANSI 61
Max. SF Amps
8.0
Diaphragm Type
Pressure Equalizing
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
Motor Mounting Position
Vertical Shaft Up
Usable @ 200V
Not Usable at 200V
Usable @ 208V
Not Usable at 208V
No. of Speeds
1
Motor Shaft Design
Spline
Sub Application
Deep Well Submersible Pump
Shaft Design
Splined
Motor Enclosure Type
Totally Enclosed Non-Ventilated
Product Type
Pump Motor
Full Load Current @ 60 Hz
6.8 A
Includes Low Temperature Monitor
Low Temperature Monitor Not Included
Series
4F
Includes Diaphragm
Diaphragm Included
Service Factor Current
8.0 A
Application
Pump
Nameplate Service Factor @ 60 Hz
1.5
Requires Overload Relay
No
Number of Speeds
1
Mounting Position
Vertical Shaft Up
Frequency
60 Hz
Bearing Type
Sleeve

Description

Deep Well Submersible Pump Motor, Body Dia. 4 in, Diaphragm Type Pressure Equalizing, Hz 60 Hz, Full Load Amps 6.8, Height 11 15/16 in, HP 3/4, Lead Length 48 in, Length Less Shaft 11 1/4 in, Max. Ambient Temp. 86 Degrees F, Max. SF Amps 8.0, Motor Application Pump, Motor Bearings Sleeve, Motor Design Split-Phase, Motor Enclosure Design Totally Enclosed Nonventilated
