Shop GENTEQ

Brushless Direct Drive Blower, ECM, 1/2 HP

  • Mfr # 6005

  • Zoro # G1536525

product price:  $315.99
/ea
Free Shipping & Returns

Key Features

Motor Sub Application
Direct Drive Fan/Blower
HP
1/2
RPM Range
1,001-1,100
Voltage
115/230V AC
Phase
Single
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
6005
Zoro #
G1536525
UPC #
815585020547
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Shaft Length
4 15/16 in
Body Dia.
5 5/8 in
Overall Length
11 1/4 in
Length Less Shaft
6 5/16 in
Lead Length
42 in
Frame Size
48
Body Diameter
5.6 in
Shaft Diameter
1/2 in

Details

Motor Sub Application
Direct Drive Fan/Blower
HP
1/2
RPM Range
1,001-1,100
Voltage
115/230V AC
Phase
Single
Motor Shaft Rotation
CW/CCW
Motor Enclosure Design
Open Air-Over
Nameplate RPM
1,075
No. of Speeds
5
Application
Fan/Blower
Includes
Adapters, Complete Wiring Harness, Extra Wire Terminals, Voltage Plugs
Max. Ambient Temp.
40 Degrees C
Motor Application
HVAC/R
Full Load Amps
6.7/4.0 A
Hz
60 Hz
Item
Direct Drive Blower Motor
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
Duty
Continuous
Motor Shaft Design
Flat
Frame
48
Motor Design
ECM
Motor Thermal Protection
None
Ins. Class
B
Motor Mounting Type
Band
Capacitor Required
No
Motor Service Factor
1
Ambient Temperature
-40 to 40 Degrees C
Motor Bearings
Ball
Motor Mounting Position
Horizontal
Motor Frame Material
Aluminum
Standards
UL Recognized (1004)
Frame Material
Aluminum
Stud Quantity
4
Number of Shafts
1
Usable @ 208V
No
Duty Cycle
Continuous
Weight
14 lb
Usable @ 200V
No
Frequency
60 Hz
Number of Speeds
5
Mounting
Band
Includes User Interface
User Interface Not Included
Wattage
370 W
Sub Application
General Purpose
Rated Horsepower
1/5 to 1/2 hp
Full Load Current @ 60 Hz
6.7/4.0 A
ECM Motor Type
Constant Torque
Ambient Temperature - Maximum
40 Degrees C
Shaft Design
Flat
Motor Enclosure Type
Open Air Over
Insulation Class
B
Nameplate Service Factor @ 60 Hz
1
Product Type
Fan and Blower Motor
Series
Evergreen(R) IM
For Motor Replacement
PSC Indoor Blower Motor
Features
Auto Rotation, Dual Voltage by Plug Selection, Multi-hp by Input Selection, Multi-Speed (5)
Bearing Type
Ball
Compatible with External Controller
Not External Control Compatible
Mounting Position
Horizontal

Description

Direct-Drive Blower Motor, ECM, 1/2 HP, Nameplate RPM 1070, Voltage 115/230, NEMA/IEC Frame 48, Open, Band Mounting, Number of Speeds 1, Full Load Amps 6.7/4.0, 60/50 Hz, 1 Phase, CW/CCW Rotation, Electronic Thermal Protection, Insulation Class B, Ball Bearings, Service Factor 1.0, Overall Length 11-1/4 In, Body Dia 5-5/8 In, Shaft Length 4-15/16 In, Shaft Dia 1/2 In, Shaft Type Flat
