Lincoln Electric Multiprocess Welder, WELD-PAK 180i, Phase Single-Phase , 120V, 230V , IncludesSpool Gun Kit K5387-6 - main

Multiprocess Welder, WELD-PAK 180i, Phase Single-Phase , 120V, 230V , IncludesSpool Gun Kit

  • Mfr # K5387-6

  • Zoro # G609768902

product price:  $1,657.99
/ea
Free Shipping & Returns

Key Features

Series
WELD-PAK 180i
Phase
Single-Phase
Input Voltage
120V, 230V
Includes
Spool Gun Kit
Features
Conveniently plugs into household 230 volt or120 volt power with included adaptor., Lightweight and portable at 34.5 lbs, Multi-Process unit capable of MIG, TIG, and Stick welding
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
K5387-6
Zoro #
G609768902
UPC #
015082696317
Country of Origin
China

Dimensions

Maximum Wire Diameter
.035
Minimum Wire Diameter
.025 in Mild Steel
For Maximum Material Thickness
5/16 in
For Minimum Material Thickness
24 ga
Overall Height
13.6 in
Overall Depth
18.1 in
Overall Width
8.9 in

Details

Item
Multiprocess Welder
Series
WELD-PAK 180i
Phase
Single-Phase
Input Voltage
120V, 230V
Includes
Spool Gun Kit
Features
Conveniently plugs into household 230 volt or120 volt power with included adaptor., Lightweight and portable at 34.5 lbs, Multi-Process unit capable of MIG, TIG, and Stick welding
Welding Processes
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW)
Model
K5387-6
Application
Home, Hobby, Shop, Farm, Autobody
MIG Welding Output @ Duty Cycle
166 A @ 22 V, 30%
Maximum Wire Feed Speed
500 in/min
TIG Welding Maximum Output Current
165 A
Effective Input Current
165A/22V/30% MIG165A/16.6V/30% TIG160A/26.4V/25% Stick
Minimum Wire Feed Speed
40 in/min
Weight
34.5 lb
Color
Red
Plug Type
230V 6-50P with a 6-50R to 5-15P 120V adapter included
MIG Welding Maximum Output Current
180 A
Open Circuit Voltage
75 V
TIG Welding Minimum Output Current
10 A
TIG Welding Output @ Duty Cycle
166 A @ 16.6 V, 30%
MIG Welding Minimum Output Current
20 A
Max. Input Current
180A @ 230V
Welding Mode
CC/CV
For Material Type
Aluminum, Stainless Steel, Steel
Stick Welding Output @ Duty Cycle
161 A @ 26.4 V, 25%
Stick Welding Maximum Output Current
161 A
Stick Welding Minimum Output Current
26 A
Polarity
DC

Description

Multiprocess Welder, Series WELD-PAK 180i, Input Voltage 120V, 230V, Phase Single-Phase, Welding Mode CC/CV, Polarity DC, Welding Processes Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW), Stick Welding Maximum Output Current 161 A, TIG Welding Maximum Output Current 165 A, MIG Welding Maximum Output Current 180 A, Maximum Wire Diameter .035, Maximum Wire Feed Speed 500 in/min, Model K5387-6, Stick Welding Output @ Duty Cycle 161 A @ 26.4 V, 25 Percent
