Shop SCHNEIDER ELECTRIC

Electronic Alarm, Alarm, Continuous, 12 to 24V DC, 0 to 105dB, ABS Plastic, White, Surface Mount

  • Mfr # XVS72BMWP
  • Zoro # G1403683
product price:
$
187.99
/ea
Free Shipping & Returns

Key Features

Housing Material
ABS Plastic
Mounting
Surface
Amps
0.280 AC
Audible Alarm Type
Alarm
Standards
EN/IEC 61000-6-2, EN/IEC 61000-6-3, UL 464, UR
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XVS72BMWP
Zoro #
G1403683
UPC #
785901811152
Country of Origin
Indonesia

Dimensions

Width
3.5 in
Height
4 in
Depth
2.7344 in
Overall Depth
69 5/16 mm
Overall Length
72 mm
Overall Width
72 mm
Wire Rope Length
72 mm
Length
72 mm
Fits Chest Size
4 Channels

Details

Item
Electronic Alarm
Housing Material
ABS Plastic
Mounting
Surface
Amps
0.280 AC
Color
White
Audible Alarm Type
Alarm
Voltage
12V DC to 24V DC
Standards
EN/IEC 61000-6-2, EN/IEC 61000-6-3, UL 464, UR
Indoor/Outdoor
Indoor
Decibels
0 to 105dB
Sound Pattern
Continuous
Visual Indicator Type
No Visual Indicator
Vibrating
No
Watts
6.7 W
Hazardous Class
II
Operating Temp.
14 Degrees to 122 Degrees F
Includes
(4) Inputs, Rotary Dials for Volume Control and Selection from 16 T
Power Source
Wire
Features
4 Channels
Wattage
6.7 W
Product Type
Alarm
Material
ABS, Polycarbonate (Terminal Cover)
Rating
IP 54
Connection Type
Wire Leads
Operating Temperature - Minimum
-10 Degrees C
Alarm Volume @ 1 m - Minimum
2 dB
Volume Selection
Selectable Volume
Control Protocol
Direct Wire
IP Rating
IP54
Sound Continuity
Continuous
Operating Current
0.117 A @ 12V, 0.125 A @ 24V, 0.158 A @ 12V, 0.200 A @ 24V
Sound Style
Tone
Includes Mounting Hardware
No Mounting Hardware
Operating Temperature - Maximum
50 Degrees C
Vibration
No Vibration
Number of Sound Patterns
16
For Location
Indoor
Alarm Volume @ 1 m - Maximum
90 dB
Mounting Style
Surface Mount
Operating Voltage
12 to 24V DC
Power Source - TS Only
Wire
Power Source - old
Wire
Shell Material
ABS, Polycarbonate (Terminal Cover)

Description

SCHNEIDER ELECTRIC XVS72BMWP is a surface-mount electronic alarm for indoor audible signaling. Rated voltage: 12 to 24V DC. Audible alarm with continuous tone output and selectable volume control; sound level specifications are listed below. The unit includes 4 channels and 16 sound patterns; dimensions are 4 in H x 3.5 in W x 2.7344 in D.

Key Features:

  • Audible alarm type: Alarm with continuous tone output
  • Sound level: 0 to 105 dB with selectable volume control; maximum 90 dB at 1 m
  • Voltage: 12 to 24V DC
  • Operating current: 0.117 A @ 12V, 0.125 A @ 24V, 0.158 A @ 12V, 0.200 A @ 24V
  • Power rating: 6.7 W
  • Sound options: 16 sound patterns and 4 channels
  • Connection and control: Wire leads with direct-wire control protocol
  • Construction: ABS plastic housing with polycarbonate terminal cover; white finish
  • Mounting: Surface mount
  • Ingress protection: IP54
  • Operating temperature: -10°C to 50°C (14°F to 122°F)
  • Includes: 4 inputs, rotary dials for volume control and tone selection
  • Standards: EN/IEC 61000-6-2, EN/IEC 61000-6-3, UL 464, UR
  • Dimensions: 4 in H x 3.5 in W x 2.7344 in D
