Shop TELEMECANIQUE SENSORS

Pressure Switch, Standard, SPDT, 1 Ports, 1/4-18" FNPT, 1.5 to 75 psi Range

  • Mfr # 9012GRO4

  • Zoro # G0527667

product price:
$
349.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4-18" FNPT
Range
1.5 to 75 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
9012GRO4
Zoro #
G0527667
UPC #
785901543190
Country of Origin
Mexico

Dimensions

Manufacturer Warranty Length
18 mo
Overall Width
2.06 in
Overall Height
5.41 in
Overall Depth
2.46 in

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4-18" FNPT
Range
1.5 to 75 psi
Factory On Setting
1.5 psi
Factory Off Setting
75 psi
Standards
CE, UL 508
Ambient Temp. Range
-10 Degrees to 185 Degrees F
Actuation Type
Diaphragm
AC Contact Rating
10A @ 480V
Series
9012G
DC Contact Rating
0.11A @ 250V, 0.22A @ 125V
Temp. Range
-10 to 185 °F
Pressure Switch Range
1.5 to 75 psi
Pressure Switch Electrical Contact Form
SPDT
Electrical Connection
Screw-Clamp Terminals
Max. Pressure
240 psi
Pressure Switch Differential
2.2 to 0.4 psi
Pressure Switch Port Type
1-Port 1/4-18 in FNPT
IP Rating
54
Differential Pressure - Maximum
2.2 psi
Proof Pressure
240 psi
Pressure - Minimum
1.5 psi
Deadband Adjustability
Fixed
Media Temperature - Maximum
250 Degrees F
Media Temperature - Minimum
-40 Degrees F
Pressure - Maximum
75 psi
Differential Pressure - Minimum
0.4 psi
Operating Temperature - Minimum
-10 Degrees F
NEMA Enclosure Rating
No Enclosure
Operating Temperature - Maximum
185 Degrees F

Description

Pressure Switch, NEMA Rating 1, Series 9012G, Temp. Range -10 Degrees to 185 Degrees F, Standards CE, UL 508, Special Features Nitrile (Buna-N) Diaphragm, Control Circuit Rated, Single Stage Switch, Open Enclosure, AC Contact Rating 3 A @ 240 V
