Pool and Spa Pump Motor, 3-Phase, 3 HP, 182VP Frame, 1,770 Nameplate RPM

  • Mfr # NO3P2BE

  • Zoro # G6164962

product price:
$
1,669.99
/ea
Additional $100.00 delivery surcharge applies per item.
See details

Key Features

Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan-Cooled
HP
3
RPM Range
1,701-1,800
Motor Service Factor
1.15
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
NO3P2BE
Zoro #
G6164962
UPC #
786382113674
Country of Origin
Mexico

Dimensions

Overall Length
18 15/16 in
Length Less Shaft
16 3/16 in
Shaft Dia.
1 1/8 in
Shaft Length
2 3/4 in
Height
11 15/16 in
Bolt Circle Dia.
9 1/8 in
Body Dia.
9.5 in
Frame Size
182VP
Bolt Circle Diameter
9 1/8 in
Body Diameter
9.5 in
Shaft Diameter
1 1/8 in
Wire Rope Length
18 15/16 in
Length
18 15/16 in

Details

Item
Pool and Spa Pump Motor
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan-Cooled
HP
3
RPM Range
1,701-1,800
Motor Service Factor
1.15
Nameplate RPM
1,770
Frame
182VP
Motor Shaft Rotation
CW/CCW
Phase
Three
Voltage
230/460V AC
Full Load Amps
7.6/3.8 A
Motor Mounting Position
Vertical
Motor Thermal Protection
None
Nominal Efficiency
89.5 %
CC Number
CC030A
Ins. Class
F
Standards
CSA Certified, cURus
Hz
60 Hz
Motor Application
Pump
Max. SF Amps
8.6/4.3
Thrust Rating
390 lb
NEMA Design
B
No. of Speeds
1
Part Winding Start Capable
Yes
Duty Cycle
Continuous
Weight
150 lb
Max. Ambient Temp.
40 Degrees C
Motor Enclosure Type
Totally Enclosed Fan Cooled
Ambient Temperature - Maximum
40 Degrees C
Nameplate Service Factor @ 60 Hz
1.15
Product Type
Pump Motor
Application
Pump
Efficiency Rating
Premium Efficiency (IE3)
Insulation Class
F
NEMA Design Class
B
Full Load Current @ 60 Hz
7.6/3.8 A
Bearing Type
Ball
Includes Low Temperature Monitor
Low Temperature Monitor Not Included
Number of Speeds
1
Service Factor Current
8.6/4.3 A
Frequency
60 Hz
Number of Wires
9

Description

Pool and Spa Pump Motor, Body Dia. 9.5 in, Bolt Circle Dia. 9 1/8 in, CC Number CC030A, Duty Cycle Continuous, Frame 182VP, Hz 60 Hz, Full Load Amps 7.6/3.8, Height 11 15/16 in, HP 3, Ins. Class F, Length Less Shaft 16 3/16 in, Max. Ambient Temp. 40 Degrees C, Max. SF Amps 8.6/4.3, Motor Application Pump, Motor Design Three-Phase, Motor Efficiency Group Premium Efficient, Motor Enclosure Design Totally Enclosed Fan-Cooled
