  11. HVAC Motor, 1/100 HP, 1550 rpm, 115V, 3.3
Dayton HVAC Motor, 1/100 HP, 1550 rpm, 115V, 3.3 71633694M - main

HVAC Motor, 1/100 HP, 1550 rpm, 115V, 3.3

  • Mfr # 71633694M

  • Zoro # G3248874

product price: $66.49
/ea

Key Features

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/100
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
71633694M
Zoro #
G3248874
UPC #
-
Country of Origin
Mexico

Dimensions

Cord Length
15 in
Length Less Shaft
3 5/8 in
Shaft Length
2 5/16 in
Shaft Dia.
1/4 in
Body Dia.
3 5/16 in

Details

Voltage
115V AC
Nameplate RPM
1,550
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/100
RPM Range
1,501-1,600
Motor Bearings
Sleeve
Item
HVAC Motor
Mounting Pattern
2-7/8
Motor Sub Application
Direct Drive Fan/Blower
Ins. Class
B
Motor Mounting Type
Ring/Stud
Motor Thermal Protection
Auto
Phase
Single
Motor Design
Shaded Pole
Number of Shafts
1
No. of Speeds
1
Motor Shaft Rotation
CWSE
Duty
Continuous
Motor Application
HVAC/R
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Stud/Base Mtg. Pattern
2-7/8 in
Hz
60 Hz
Max. Ambient Temp.
40 Degrees C
Frame
3.3
Application
OEM and Replacement Use In A Wide Variety of Fan and Blower
Motor Shaft Design
Flat
Full Load Amps
0.65 A
Mounting Stud Location
2/Both Ends
Motor Service Factor
1
Capacitor Required
No
Usable @ 208V
No
Mounting Stud Pattern
2 7/8 in
Duty Cycle
Continuous
Motor Mounting Position
All Angle
Usable @ 200V
No
Type
OEM Replacement
Mounting
Stud

Description

HVAC Motor, Single Phase, Motor Design Shaded Pole, 1/100 hp HP, Nameplate RPM 1,550 RPM, No. of Speeds 1, Voltage 115V AC, 0.65 A Full Load Amps, 3.3 Frame, Output Watts 7.4 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWSE, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud, Motor Frame Material Steel
