Heavy Duty Limit Switch, Plunger, 1NC/1NO, 10A at 600V AC, Actuator Location: Side

  • Mfr # E50AS26P

  • Zoro # G5233085

product price:  $566.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
E50AS26P
Zoro #
G5233085
UPC #
782113134734
Country of Origin
Mexico

Dimensions

Actuator Length - Limit Switch
1.97 in
Depth
2.25"
Body Height - Limit Switch
3.13 in
Body Width - Limit Switch
1.54 in
Actuator Length
1.97"
Body Depth - Limit Switch
1.78 in
Height
1.09"
Width
1.54"
Arm Width
0.31 in
Arm Depth
0.32 in
Manufacturer Warranty Length
1 yr
Overall Height
4.67 in
Body Height
3.13 in
Mounting Hole Diameter
0.2 in
Arm Length - Maximum
0.31 in
Overall Width
2.79 in
Body Depth
1.58 in
Overall Depth
1.54 in
Body Width
1.54 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
Not Rated
Body Style - Limit Switch
Standard
Mounting - Limit Switch
Surface
Contact Form
1NO/1NC
Body Style (Limit Switch)
Standard
Actuator Location
Side
DC Contact Rating
1 A @ 250 V
Stem Thread - Limit Switch
No Stem
Actuator Style (Limit Switch)
Plunger
IP Rating
IP67, IP69K
Electrical Connection
8 ft Cable
Boot Sealed Actuator - Limit Switch
No
Mounting Hole Spacing - Limit Switch
2.34 in x 1.16 in
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
Series
E50
Contact Form - Limit Switch
1NC/1NO
NEMA Rating
3, 3S, 4X, 6P
Voltage Rating
600VAC
Movement
Linear
Operating Force
4.0 in-lb
Boot Sealed Actuator (Limit Switch)
No
Mounting Hole - Limit Switch
(2) 0.20 in dia
Actuator Location (Limit Switch)
Side
Actuator Style
Plunger
Operating Temp. Range
14 Degrees to 250 Degrees F
AC Contact Rating
10 A @ 240 V
Travel
Operating Travel 0.065 in, Reset Travel 0.03 in, Total Travel 0.25 in
Wiring Entry
1/2 in NPT
Basic Actuator Style (Limit Switch)
Plunger
Limit Switch Style
Heavy Duty Limit Switch
Amps
10
Standards
CE, CSA, UL Listed
Body Material
Zinc
Arm Material
Metal
Differential Travel
0.25 in
Connection Type
8 ft (2.4 m) cable
Certification
UL Listed
Weight
2.1 lb
Mounting Hole Vertical Center to Center Distance
29 mm
Arm Adjustability
Adjustable
Plunger Adjustability
Adjustable
Boot Sealed Actuator
Boot Included
Reset Travel
0.03 in
NEMA Enclosure Rating
1, 13, 3, 3S, 4, 4X, 6, 6P
Directional Movement
Linear
Operating Force - Maximum
4 lbf
Body Configuration
Plug-In
Operating Torque - Maximum
18 in-lb
Operating Temperature - Maximum
201 Degrees F
Mounting Style
Surface
Overtravel
0.25 in
Pretravel
0.03 in
Number of Mounting Holes
2
Roller Position
Side
Action
Momentary/Momentary
Lamp Type
No Lamp Module Included
Includes Actuator
Actuator Included
Mounting Hole Horizontal Center to Center Distance
59 mm
Operating Force - Minimum
8 ozf
Operating Temperature - Minimum
14 Degrees F
Total Travel
0.25 in
Operating Torque - Minimum
4 in-lb

Description

Plunger Limit Switch, Actuator Style - Limit Switch Plunger, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch Not Rated, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 1.97 in, Body Height - Limit Switch 3.13 in, Body Width - Limit Switch 1.54 in, Body Depth - Limit Switch 1.78 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Standard, NEMA Rating 3, 3S, 4X, 6P
