Shop EDWARDS SIGNALING

Horn Strobe, Horn, Continuous, 24 V AC, 24V DC, 90 dB, Thermoplastic, Clear Lens, Gray Housing

  • Mfr # 869STRC-AQ

  • Zoro # G5708211

product price:  $356.99
/ea
Free Shipping & Returns

Key Features

Housing Material
Thermoplastic
Mounting
Surface
Amps
412 mA @ 24V DC, 462 mA @ 24V AC
Audible Alarm Type
Horn
Standards
UL Listed
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
869STRC-AQ
Zoro #
G5708211
UPC #
782640239667
Country of Origin
Mexico

Dimensions

Width
5.5 in
Height
5.5 in
Depth
0.625 in
Overall Width
5 1/2 in
Overall Depth
5/8 in
Overall Length
5 1/2 in

Details

Item
Horn Strobe
Housing Material
Thermoplastic
Mounting
Surface
Amps
412 mA @ 24V DC, 462 mA @ 24V AC
Color
Clear Lens, Gray Housing
Audible Alarm Type
Horn
Voltage
24 V AC, 24V DC
Standards
UL Listed
Indoor/Outdoor
Indoor
Decibels
90 dB
Sound Pattern
Continuous
Visual Indicator Type
Strobe
Lens Color
Clear
Current Drawn
462 mA @ 24V AC, 412 mA @ 24V DC
Housing Color
Gray
Light Output
150 CP
Flashes per Minute
60
Vibrating
No
Operating Temp.
-31 Degrees to 150 Degrees F Outdoor, 32 Degrees to 120 Degrees F Indoor
Power Source
Wire
Product Type
Horn and Strobe
Operating Current
0.462 A @ 24V AC, 0.412 A @ 24V DC
Sound Continuity
Continuous
Mounting Style
Flush Mount
Vibration
No Vibration
Operating Temperature - Maximum
120 Degrees F
For Location
Indoor
Brightness Selection
Fixed Brightness
Light Operating Mode
Strobe
Connection Type
Wire Leads
Sound Style
Horn
Light Intensity
150 CP
Alarm Volume @ 1 m - Maximum
100 dB
Operating Temperature - Minimum
32 Degrees F
Number of Sound Patterns
1
Alarm Volume @ 10 ft - Maximum
90 dB
Light Source
Xenon
Control Protocol
Direct Wire
Operating Voltage
24 V AC, 24V DC

Description

EDWARDS SIGNALING 869STRC-AQ is an indoor horn strobe that includes audible and visual signaling components. This direct-wire unit combines a continuous horn with a xenon strobe in a flush-mount format for facility alarm and notification applications using both sound and light indication.

Key Features:

  • Horn and strobe combination with continuous audible output and visual strobe indicator
  • Operates on 24V AC or 24V DC
  • Sound level: 90 dB at 10 ft maximum; 100 dB at 1 m maximum
  • Current draw: 462 mA at 24V AC; 412 mA at 24V DC
  • Light output: 150 CP with xenon light source and 60 flashes per minute
  • Thermoplastic housing with clear lens and gray finish
  • Wire lead connection; direct-wire control protocol
  • Flush-mount installation
  • Dimensions: 5.5 in. H x 5.5 in. W x 0.625 in. D
  • Indoor operating temperature: 32°F to 120°F
  • UL Listed
