Shop SCHNEIDER ELECTRIC

Siren, Siren, Continuous, 24V DC, 0 to 105dB, ABS Plastic, White, Pivot/Swivel Mount

  • Mfr # XVS14BMW

  • Zoro # G1244381

product price:
$
382.99
/ea
Free Shipping & Returns

Key Features

Housing Material
ABS Plastic
Mounting
Pivot/Swivel
Amps
0.400 AC
Color
White
Audible Alarm Type
Siren
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
XVS14BMW
Zoro #
G1244381
UPC #
785901811237
Country of Origin
Indonesia
Item
Siren
Housing Material
ABS Plastic
Mounting
Pivot/Swivel
Amps
0.400 AC
Color
White
Audible Alarm Type
Siren
Voltage
24V DC
Standards
EN 55014-2, EN 55022, EN 61000-6-2, EN 61000-6-3, UL Listed
Indoor/Outdoor
Indoor
Decibels
0 to 105dB
Sound Pattern
Continuous
Watts
4.8 W
Operating Temp.
14 Degrees to 122 Degrees F
Hazardous Class
II
Visual Indicator Type
No Visual Indicator
Vibrating
No
Includes
1.6 ft Cord, Input, Rotary Dials for Volume Control and Selection from 43 T
Power Source
Wire
Features
It is Part of the Range Harmony XVS Sirens and Electronics Alarms Range
Wattage
4.8 W
Rating
IP 53
Material
ASA, Polycarbonate
Product Type
Siren
Vibration
No Vibration
Volume Selection
Selectable Volume
Operating Current
0.250 A @ 12V, 0.350 A @ 24V
Sound Continuity
Continuous
Number of Sound Patterns
43
Operating Temperature - Maximum
50 Degrees C
Operating Temperature - Minimum
-10 Degrees C
Alarm Volume @ 1 m - Minimum
0 dB
Alarm Volume @ 1 m - Maximum
105 dB
For Location
Indoor
Sound Style
Siren
IP Rating
IP53
Connection Type
Wire Leads
Includes Mounting Hardware
No Mounting Hardware
Control Protocol
Direct Wire
Mounting Style
Surface Mount
Operating Voltage
24V DC
Power Source - TS Only
Wire
Power Source - old
Wire

Description

SCHNEIDER ELECTRIC XVS14BMW is a 24V DC continuous siren for indoor audible signaling. It provides selectable sound output from 0 to 105 dB at 1 m and includes 43 sound patterns with rotary dials for volume control and tone selection. The unit has a white housing made from ABS plastic, ASA, and polycarbonate, along with a pivot/swivel surface-mount design.

Key Features:

  • Audible alarm type: siren with continuous sound pattern
  • Sound output: 0 to 105 dB at 1 m
  • Voltage: 24V DC
  • Power consumption: 4.8 W
  • Operating current: 0.250 A @ 12V, 0.350 A @ 24V
  • Connection type: wire leads; control protocol: direct wire
  • Volume selection: selectable volume with rotary dials
  • Sound patterns: 43 selectable tones
  • Housing/materials: ABS plastic, ASA, and polycarbonate
  • Mounting: pivot/swivel, surface mount
  • Ingress protection: IP53
  • Operating temperature: 14°F to 122°F (-10°C to 50°C)
  • Visual indicator type: no visual indicator
  • Includes: 1.6 ft cord and input controls
  • Standards: multiple EN standards; UL Listed
