Condenser Fan Motor, 1/4 hp

  • Mfr # D742
  • Zoro # G6422766
product price:
$
171.99
/ea
Free Shipping & Returns

Key Features

Full Load Amps
2.1 A
Standards
CSA Certified, UL Recognized
Phase
Single
Stud Size
#8-32
Motor Mounting Position
All Angle
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
D742
Zoro #
G6422766
UPC #
818508021300
Country of Origin
Thailand
Full Load Amps
2.1 A
Item
Condenser Fan Motor
Standards
CSA Certified, UL Recognized
Phase
Single
Motor Mounting Position
All Angle
Mounting Stud Pattern
3 11/16 in x 3 11/16 in
Motor Design
Permanent Split Capacitor
RPM Range
1,001-1,100
Hz
60 Hz
Motor Bearings
Sleeve
Ins. Class
B
Max. Ambient Temp.
40 Degrees C
Application
Condenser Fan
Motor Application
HVAC/R
Motor Shaft Design
Double-Flat
Voltage Compatibility
115V AC, 208V AC to 230V AC, 200V AC to 230V AC, 208V AC to 220V AC, 440V AC, 208V AC to 230V AC, 277V AC, 208V AC to 230V AC, 440V AC, 208V AC to 230V AC, 460V AC, 208V AC to 230V AC, 208V AC to 240V AC
Stud Quantity
4
Nameplate RPM
1,075
Features
Belly Band, Extended Studs Lead End, Thermally Protected
Voltage
208V AC to 230V AC
Motor Service Factor
1
Motor Enclosure Design
Open Dripproof
HP
1/4
Motor Mounting Type
Stud
Motor Thermal Protection
Auto
Nominal Efficiency
60 %
Motor Sub Application
Condenser Fan
Motor Shaft Rotation
CW/CCW
Duty
Continuous
Capacitor Required
Capacitor Included
No. of Speeds
1
Frame
48
Removable Base
Yes
Usable @ 208V
Usable at 208V
Motor Frame Material
Steel
Usable @ 200V
Not Usable at 200V
Weight
11 lb
Duty Cycle
Continuous
Output Watts
190 W
Insulation Class
B
Full Load Current @ 60 Hz
2.1 A
Wattage
190 W
Motor Enclosure Type
Open Drip Proof
Includes
Removable Base
Number of Speeds
1
Drive Type
Direct Drive
Ambient Temperature - Maximum
40 Degrees C
Frequency
60 Hz
Product Type
Condenser Fan Motor
Sub Application
Condenser Fan
Nameplate Service Factor @ 60 Hz
1
Shaft Design
Double Flat
Manufacturers Warranty
1 yr
Bearing Type
Sleeve
Mounting Position
All Angle
Frame Material
Steel

Dimensions

Stud Size
#8-32
Body Dia.
5 5/8 in
Manufacturers Warranty Length
1 yr
Bolt Circle Dia.
5 1/4 in
Shaft Length
6 in
Length Less Shaft
5 3/16 in
Overall Length
10 11/16 in
Lead Length
27 in
Shaft Dia.
1/2 in
Shaft Diameter
1/2 in
Body Diameter
5.6 in
Mounting Stud Thread Size
#8-32
Bolt Circle Diameter
5 1/4 in
Frame Size
48
Wire Rope Length
10 11/16 in
Length
10 11/16 in

Description

Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/4 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 208-230V AC, 2.1 A Full Load Amps, 48 Frame, Output Watts 190 W, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Stud
