Fasco HVAC Motor, 1/20 HP, 1500 rpm, 230V, 3.3 D188 - main

HVAC Motor, 1/20 HP, 1500 rpm, 230V, 3.3

  • Mfr # D188

  • Zoro # G5229411

product price:  $74.59
/ea

Key Features

Voltage
230V AC
Nameplate RPM
1,500
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/20
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
D188
Zoro #
G5229411
UPC #
663001024880
Country of Origin
Mexico

Dimensions

Length Less Shaft
3 3/8 in
Shaft Dia.
5/16 in
Shaft Length
2 1/4 in
Body Dia.
3 5/16 in
Lead Length
12 in
Bolt Circle Dia.
2 7/8 in
Stud Size
#8-32
Overall Length
5 1/2 in
Mounting Stud Thread Size
#8-32
Body Diameter
3.3 in
Shaft Diameter
5/16 in
Frame Size
3.3
Bolt Circle Diameter
2 7/8 in

Details

Voltage
230V AC
Nameplate RPM
1,500
Motor Enclosure Design
Open Air-Over
Number of Speeds
1
HP
1/20
RPM Range
1,401-1,500
Stud/Base Mtg. Pattern
2-7/8 in x 2-7/8 in
Motor Sub Application
Direct Drive Fan/Blower
Hz
60 Hz
Mounting Stud Location
4/Both Ends
Motor Thermal Protection
Auto
Motor Service Factor
1
Motor Bearings
Sleeve
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
Motor Mounting Type
Ring/Stud
No. of Speeds
1
Max. Ambient Temp.
40 Degrees C
Item
Fan and Blower Motor
Number of Shafts
1
Motor Design
Shaded Pole
Frame
3.3
Full Load Amps
0.9 A
Phase
Single
Application
Fan/Blower
Standards
CSA Certified, UL Recognized
Ins. Class
B
Motor Shaft Rotation
CWSE
Mounting Pattern
2-7/8 x 2-7/8
Duty
Continuous
Motor Application
HVAC/R
Motor Shaft Design
Flat
Capacitor Required
Capacitor Not Required
Usable @ 200V
Not Usable at 200V
Motor Frame Material
Steel
Weight
3 lb
Mounting Holes
(8) #8-32
Mounting Stud Pattern
2 7/8 in x 2 7/8 in
Motor Mounting Position
All Angle
Usable @ 208V
Not Usable at 208V
Mounting
Stud
Bearing Type
Sleeve
Product Type
Fan and Blower Motor
Full Load Current @ 60 Hz
0.9 A
Wattage
40 W
Drive Type
Direct Drive
Frame Material
Steel
Nameplate Service Factor @ 60 Hz
1
Shaft Design
Flat
Sub Application
General Purpose
Frequency
60 Hz
Insulation Class
B
Motor Enclosure Type
Open Air Over
Ambient Temperature - Maximum
40 Degrees C

Description

Fan and Blower Motor, Single Phase, Motor Design Shaded Pole, 1/20 hp HP, Nameplate RPM 1,500 RPM, No. of Speeds 1, Voltage 230V AC, 0.9 A Full Load Amps, 3.3 Frame, Output Watts 40 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CWSE, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud, Motor Frame Material Steel
