Shop FEDERAL SIGNAL

Electronic Sounder, Siren, Continuous, 12 to 24V AC/DC, 120 to 240V AC, 55 to 95dB, 65 to 105dB

  • Mfr # SLM700R

  • Zoro # G3345437

product price:  $147.99
/ea
Free Shipping & Returns

Key Features

Housing Material
Polycarbonate
Mounting
Conduit, Surface
Amps
35 to 240mA
Diameter
3.9063 in
Audible Alarm Type
Siren
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SLM700R
Zoro #
G3345437
UPC #
782979232117
Country of Origin
Italy

Dimensions

Diameter
3.9063 in
Height
2.4375 in
Depth
3.9063 in
Width
3.9063 in
Overall Depth
2 7/16 in
Overall Diameter
3 7/8 in

Details

Item
Electronic Sounder
Housing Material
Polycarbonate
Mounting
Conduit, Surface
Amps
35 to 240mA
Color
Red
Audible Alarm Type
Siren
Voltage
12 to 24V AC/DC, 120 to 240V AC
Standards
CE, cUL Listed, UL Listed
Indoor/Outdoor
Indoor, Outdoor
Decibels
55 to 95dB, 65 to 105dB
Sound Pattern
Continuous
Operating Temp.
-22 Degrees to 122 Degrees F
Current Drawn
35 to 240mA
Includes
Top Module
Lens Color
Red
Visual Indicator Type
No Visual Indicator
Housing Color
Red
Vibrating
No
Alarm Type
Audible
Features
Produces Two Tones at Three Adjustable Tone Levels
Material
Polycarbonate
Rating
IP 65, NEMA 3R
Product Type
Sounder Module
IP Rating
IP65
Alarm Volume @ 1 m - Minimum
86 dBA
Alarm Volume @ 1 m - Maximum
105 dBA
Number of Sound Patterns
32
Operating Current
0.060 A @ 24DC, 0.085 A @ 12V DC, 0.090 A @ 240V AC, 0.125 A @ 120V AC, 0.190 A @ 24V AC, 0.280 A @ 12V AC
Vibration
No Vibration
Alarm Volume @ 10 ft - Maximum
95 dBA
Operating Temperature - Minimum
-40 Degrees F
NEMA Rating
NEMA 3R
Alarm Volume @ 10 ft - Minimum
76 dBA
Sound Style
Siren
Mounting Style
Surface Mount
Sound Continuity
Continuous
Operating Temperature - Maximum
131 Degrees F
For Location
Outdoor
Operating Voltage
12 to 24V AC/DC, 120 to 240V AC

Description

Federal Signal SLM700R is an electronic sounder module with an audible siren output for alarm and warning notification. It provides continuous sound operation with 32 sound patterns and two tones at three adjustable tone levels. The unit is rated for 12 to 24V AC/DC and 120 to 240V AC operation, with IP65 and NEMA 3R ratings for indoor and outdoor signaling system installations.

Key Features:

  • Alarm Type: Audible siren with no visual indicator.
  • Sound Output: 55 to 95 dB and 65 to 105 dB; maximum output is 105 dBA at 1 m and 95 dBA at 10 ft.
  • Sound Pattern: Continuous sound operation with 32 sound patterns.
  • Adjustability: Two tones at three adjustable tone levels.
  • Voltage: 12 to 24V AC/DC, 120 to 240V AC.
  • Current Draw: 35 to 240 mA; operating current includes 0.060 A at 24V DC, 0.085 A at 12V DC, 0.090 A at 240V AC, 0.125 A at 120V AC, 0.190 A at 24V AC, and 0.280 A at 12V AC.
  • Construction: Red polycarbonate housing.
  • Mounting: Surface and conduit mounting.
  • Protection Ratings: IP65 and NEMA 3R.
  • Operating Temperature: -40°F to 131°F.
  • Standards: CE, cUL Listed, UL Listed.
