Carbide Turning Insert, Parallelogram, ZCMX080308, for Steel
Mfr # 268427 HBZ025
Zoro # G214821931
product price: $18.29
/eaSold in multiples of 10 for $182.90
Key Features
Suitable Tool Diameter
16 mm
Insert Size
80308
Grade
HBZ025
Insert Style
ZCMX
Inscribed Circle
8 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268427 HBZ025
Zoro #
G214821931
UPC #
-
Country of Origin
Austria
Dimensions
Suitable Tool Diameter
16 mm
Insert Size
80308
Insert Thickness
2 mm
Cutting Depth
0.4 mm
Corner Radius
0.8 mm
Min. Cutting Depth (ap min)
0.55 mm
Max. Cutting Depth (ap max)
2.75 mm
Details
Grade
HBZ025
Insert Style
ZCMX
Inscribed Circle
8 mm
Item
Indexable Insert for Turning
Workpiece Material
Steel
No. of Edges
2
Coating
PVD
ISO Number
ZCMX 080308
Insert Shape
Parallelogram
Cutting Conditions
Continuous
Insert Material
Carbide
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 16 mm Grade: HBZ025 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 90 210 m/min
