Shop LEESON

3, 1725, Dp, 56Hz, 3/60/208-230/460

  • Mfr # 056T17D5350

  • Zoro # G0767597

product price:  $506.99
/ea
Free Shipping & Returns

Key Features

Frame
56HZ
HP
3.0 HP
Motor Application
OEM Replacement
Motor Design
Squirrel Cage Induction Run
Motor Enclosure Design
Drip Proof
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
056T17D5350
Zoro #
G0767597
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8"
Shaft Length
2.28"
Length Less Shaft
12 7/16 in
Body Dia.
6 7/16 in
Manufacturers Warranty Length
1 yr
Overall Length
14.72"
Wire Rope Length
14 23/32 in
Shaft Diameter
7/8 in
Frame Size
56HZ
Body Diameter
6.5 in

Details

Frame
56HZ
HP
3.0 HP
Item
Motor
Motor Application
OEM Replacement
Motor Design
Squirrel Cage Induction Run
Motor Enclosure Design
Drip Proof
Motor Mounting Type
Resilient Base
Motor Shaft Rotation
Reversible
Motor Thermal Protection
Auto
Nameplate RPM
1,725
No. of Speeds
1
Number of Shafts
1
Phase
3
RPM Range
1,701-1,800
Voltage
208-230/460V
Motor Bearings
Ball
Ins. Class
B
Max. Ambient Temp.
40 Degrees C
Duty
Continuous
Full Load Amps
9.2-8.6/4.3A
Standards
UL Recognized, CSA Certified
Motor Shaft Design
NEMA 145T
Hz
60 Hz
Motor Service Factor
1.00
Terminal Type
1/4" Male Quick-Connect
Usable @ 208V
Yes
Weight
48 lb
Duty Cycle
Continuous
Motor Mounting Position
Horizontal
Nominal Efficiency
84 %
Motor Frame Material
Rolled Steel
Full Load Current @ 60 Hz
9.2-8.6/4.3 A
Motor Enclosure Type
Open Drip Proof
Bearing Type
Ball
Product Type
Fan and Blower Motor
Frame Material
Steel
Insulation Class
B
Sub Application
Condenser Fan
Drive Type
Belt Drive
Mounting Position
Horizontal
Frequency
60 Hz
Number of Speeds
1
Nameplate Service Factor @ 60 Hz
1.15
Ambient Temperature - Maximum
40 Degrees C
Application
Fan/Blower
Shaft Design
Keyed

Description

Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 9.2-8.6/4.3 A Full Load Amps, 56HZ Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel
