Shop MILLER ELECTRIC

Multiprocess Welder, Multimatic 220 AC/DC, Phase Single-Phase , 110/115/120V AC, 220/230/240V AC

  • Mfr # 907757002

  • Zoro # G816035187

product price:
$
5,919.99
/ea
Free Shipping & Returns
Zoro's best price: not eligible for any other offers or promotions

Key Features

Series
Multimatic 220 AC/DC
Phase
Single
Input Voltage
110/115/120/220/230/240V AC
Includes
Material Thickness Gauge, 10 ft Work Cable with Clamp and 25 mm Dinse-Style Connector, 10 ft MDX(TM)-100 MIG Welding Gun, 12.5 ft Weldcraft(TM) A-150 (WP-17) TIG Torch with 25 mm Dinse-Style Connector, 13 ft Cable Electrode Holder and 25 mm Dinse-Style Connector, Wireless Foot Control System, 6.5 ft Power Cord and MVP(TM) Adapter Plugs for 120V and 240V, Dual Cylinder Running Gear, Hook-and-Loop Cord Wraps, Multimatic 220 AC/DC, 0.030 in (0.8 mm) Solid Wire, Two Argon and AR/CO2 mix Regulator/Flow Gauge with Hoses, (2) Contact Tips for 0.030 in (0.8 mm) Wire
Overall Height
17.5 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
907757002
Zoro #
G816035187
UPC #
715959711470
Country of Origin
United States
Item
Multiprocess Welder
Series
Multimatic 220 AC/DC
Phase
Single
Input Voltage
110/115/120/220/230/240V AC
Includes
Material Thickness Gauge, 10 ft Work Cable with Clamp and 25 mm Dinse-Style Connector, 10 ft MDX(TM)-100 MIG Welding Gun, 12.5 ft Weldcraft(TM) A-150 (WP-17) TIG Torch with 25 mm Dinse-Style Connector, 13 ft Cable Electrode Holder and 25 mm Dinse-Style Connector, Wireless Foot Control System, 6.5 ft Power Cord and MVP(TM) Adapter Plugs for 120V and 240V, Dual Cylinder Running Gear, Hook-and-Loop Cord Wraps, Multimatic 220 AC/DC, 0.030 in (0.8 mm) Solid Wire, Two Argon and AR/CO2 mix Regulator/Flow Gauge with Hoses, (2) Contact Tips for 0.030 in (0.8 mm) Wire
Remote Connection Type
14-Pin (Miller)
For Material Type
Aluminum, Stainless Steel, Steel
Input Frequency
50/60 Hz
TIG Arc Start Feature
High Frequency Start
TIG Welding Maximum Output Current
210 A
Max. Input Current
230 A
Stick Welding Minimum Output Current
30 A
For Wire Type
Flux-Cored, Solid
Features
Generator Compatible
MIG Welding Minimum Output Current
30 A
Polarity
AC/DC
TIG Welding Output @ Duty Cycle
130 A @ 15.2 V, 40%, 210 A @ 18.4 V, 20%
Standards
cCSAus
Plug Type
5-15P, 6-50P
Welding Mode
CC/CV
Power Cord Included
Yes
Stick Welding Output @ Duty Cycle
200 A @ 28.4 V, 15%, 90 A @ 23.6 V, 40%
Color
Black, Blue
Model
220
Weight
56 lb
Stick Welding Maximum Output Current
200 A
Application
Welding Education and Training
MIG Welding Maximum Output Current
230 A
Minimum Wire Feed Speed
60 in/min
Welding Processes
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW)
Maximum Wire Feed Speed
600 in/min
MIG Welding Output @ Duty Cycle
105 A @ 19.2 V, 60%, 170 A @ 21.5 V, 40%, 200 A @ 24 V, 20%
Effective Input Current
21.5 A @ 240V, 22.4 @ 240V, 23.3 A @ 120V, 24.0 A@ 120V, 24.5 A @ 240V, 27.2 A @ 240V, 31.3 A @ 240V
Enhanced Process
Pulsed MIG (GMAW-P)
TIG Welding Minimum Output Current
20 A
Open Circuit Voltage
46 V DC
Amperage TIG - Minimum
20 A
Rated Output @ Duty Cycle (Stick)
200 A @ 28.4 V, 15%, 90 A @ 23.6 V, 40%
Amperage Stick - Maximum
200 A
Process
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW), DC TIG Welding (GTAW-DC)
Amperage TIG - Maximum
210 A
TIG Arc Control Feature
Arc Control
Maximum Input Current
230 A
Rated Output @ Duty Cycle (MIG)
105 A @ 19.2 V, 60%, 170 A @ 21.5 V, 40%, 200 A @ 24 V, 20%
Amperage Stick - Minimum
30 A
Amperage MIG - Minimum
30 A
Welding Power Source Type
CC/CV
Rated Output @ Duty Cycle (TIG)
130 A @ 15.2 V, 40%, 210 A @ 18.4 V, 20%
Amperage MIG - Maximum
230 A

Description

Multiprocess Welder, Series Multimatic 220 AC/DC, Input Voltage 110/115/120V AC, 220/230/240V AC, Phase Single-Phase, Welding Mode CC/CV, Polarity AC/DC, Input Frequency 50/60 Hz, Welding Processes Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW), Stick Welding Maximum Output Current 200 A, TIG Welding Maximum Output Current 210 A, MIG Welding Maximum Output Current 230 A, For Wire Type Flux-Cored, Solid, Maximum Wire Diameter 0.035 in (Solid)
