Shop DAYTON

Fan Mtr, 3/4HP, 1140, 220-230/460

  • Mfr # 31TR59

  • Zoro # G8571132

product price:  $613.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
3/4
RPM Range
1,101-1,200
No. of Speeds
1
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
31TR59
Zoro #
G8571132
UPC #
190735255650
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8 in
Shaft Length
6 in
Stud Size
#10-32
Length Less Shaft
8 3/4 in
Bolt Circle Dia.
5 7/8 in
Overall Length
14 3/4 in
Body Dia.
6 1/2 in
Lead Length
6 in
Bolt Circle Diameter
5 7/8 in
Frame Size
56Z
Shaft Diameter
5/8 in
Mounting Stud Thread Size
#10-32
Body Diameter
6.5 in
Wire Rope Length
14 3/4 in

Details

Item
Condenser Fan Motor
Motor Design
Three-Phase
Phase
Three
HP
3/4
RPM Range
1,101-1,200
No. of Speeds
1
Voltage
208-230/460V AC
Motor Shaft Rotation
CW/CCW
Frame
56Z
Motor Enclosure Design
Open Air-Over
Motor Mounting Type
Band
Motor Mounting Position
Horizontal or Vertical Shaft Up
Motor Thermal Protection
Auto
Max. Ambient Temp.
60 Degrees C
Nameplate RPM
1,140
Motor Application
HVAC/R
Motor Sub Application
Condenser Fan
Voltage Compatibility
200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC
Capacitor Required
Capacitor Not Required
Motor Bearings
Ball
Stud Quantity
4
Application
Condenser Fan
Ins. Class
F
Duty
Continuous
Standards
CSA 258525, UL E47479
Mounting Stud Pattern
4 1/8 in x 4 1/8 in
Nominal Efficiency
82 %
Features
Quick Disconnect Design
Full Load Amps
2.8-2.8/1.4 A
Motor Service Factor
1
Motor Shaft Design
Flat
Hz
60 Hz
Duty Cycle
Continuous
Mounting
Band
Shaft Design
Flat
Bearing Type
Ball
Mounting Position
Horizontal/Vertical Shaft Up
Motor Enclosure Type
Open Air Over
Product Type
Condenser Fan Motor
Frequency
60 Hz
Sub Application
Condenser Fan
Full Load Current @ 60 Hz
2.8-2.8/1.4 A
Nameplate Service Factor @ 60 Hz
1
Drive Type
Direct Drive
Number of Speeds
1
Insulation Class
F
Ambient Temperature - Maximum
60 Degrees C

Description

Condenser Fan Motor, Three Phase, Motor Design Three-Phase, 3/4 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 2.8-2.8/1.4 A Full Load Amps, 56Z Frame, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class F, Duty Cycle Continuous, Max. Ambient Temp. 60 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Belly Band, Motor Mounting Position Horizontal/Vertical Shaft Up, Shaft Length 6 in
